Product Summary

FEATURES
? 10/100/1000BASE-T IEEE 802.3 compliant
? Supports GMII, TBI, reduced pin count GMII
(RGMII), reduced pin count TBI (RTBI), and serial
GMII (SGMII) interfaces
? Integrated 1.25 GHz SERDES for 1000BASE-X
fiber applications
? Four RGMII timing modes
? Energy Detect and Energy Detect+ low power
modes
? Three loopback modes for diagnostics
? “Downshift” mode for two-pair cable installations
? Fully integrated digital adaptive equalizers, echo
cancellers, and crosstalk cancellers
? Advanced digital baseline wander correction
? Automatic MDI/MDIX crossover at all speeds of
operation
? Automatic polarity correction
? IEEE 802.3u compliant Auto-Negotiation
? Software programmable LED modes including LED
testing
? Automatic detection of fiber or copper operation
? Supports IEEE 1149.1 JTAG
? Two-Wire Serial Interface (TWSI) and MDC/MDIO
? CRC checker, packet counter
? Packet generation
? Virtual Cable Tester (VCT)
? Auto-Calibration for MAC Interface outputs
? Requires only two supplies: 2.5V and 1.0V (with
1.2V option for the 1.0V supply)
? I/Os are 3.3V tolerant
? Low power dissipation Pave = 0.75W
? 117-Pin TFBGA, 96-Pin BCC, and 128 PQFP
package options
? 117-Pin TFBGA and 96-Pin BCC packages available in Commercial or Industrial grade
? RoHS 6/6 compliant packages available
